| 主板 | Intel® Atom™ processor E3815, BGA type |
| 内存 | DDR3 1066 SO-DIMM memory, Max. 8GB |
| LAN | 4 x LAN Chip: Intel® i210-IT |
| Support 10/100/1000 link speed |
| 4 x copper ports |
| 前面板I/O接口 | 2 x USB2.0 port |
| 4 x RJ45 port (bypass function 1 pair) |
| 1 x VGA (internal debug) |
| 2 x DC input 1 x 2-pin |
| 1 x Reset button1 x GPIO button |
| Power status/bypass status/CFast status |
| 后面板I/O接口 | 2 x Console Port (support RS232/RS422/RS485) |
| 1 x CFast |
| 存储 | None |
| 电源输入 | Redundant DC input power adapter (65W), support +9V to +30VDC input |
| 尺寸 | Chassis dimension: 190 mm x 140 mm x 70 mm |
| Carton dimension: 301 mm x 268 mm x 250 mm |
| 重量 | Without packing: 2.2 Kg |
| With packing: 3.8 Kg |
| 环境 | Operating temperature: -40°C~70°C |
| Storage temperature: -40°C~85°C |
| Relative humidity: 5%~95% non-condensing |
| 通过认证 | CE approval FCC Class A UL |
