General | Cooling: System FanlessEnclosure: Plastic PC + ABS with aluminum die casting heatsinkMounting: Support VESA 75, stand mountingDual SMA Type antenna connectors of BT/ Wi-Fi / WWANPower Input: 9~36VDC input with IgnitionPower Consumption: 16WIngress Protection: IP54Dimension: 185.4mm (W) x 141.4mm (H) x 50.42mm (D)
(7.3" x 5.57" x 1.99")Weight: 1Kg, 2.20Lb |
LCD 屏 | 7-inch TFT LCD Panel with LED Backlight800 x 480 pixels (WVGA)Brightness: 500 cd/m² (typical)Contrast Ratio: 600:1 (typical) |
触摸屏传感器 | 4-wire resistant touchAnti-Glare Coating SurfaceTransmission Rate: 82 ± 3% |
CPU & 芯片组 | Intel® Atom™ E640 1.0GHzEG20T |
内存 | On-board DDR2 1GB |
存储接口 | 1 x mSATA |
扩展 | Mini-PCIe socket (PCIe + USB+SATA) x 1 (for WLAN module)Mini-PCIe socket (USB) x 1 (for 3.5G module) |
正面接口 | 5 x Control buttons
Power on/off
Volume control (+/-)
Brightness control (+/-)Light Sensor2 x LED indicators2 x Built-in speakers (1W) |
侧面 I/O | 1 x Line-in1 x Line-out1 x USB1 x SIM slot1 x Power Button1 x Reset Button |
底部接口 | 1 x DB9 male connector (RS-232)1 x DB37 female connector (1 x LAN; 2 x USB; 1x RS-232; 1 x RS422/ 485; 6 x GPIO)6~36V wide range DC power input1 x SMA connector for GPS antenna |
可选通讯模块 | 1 x Wireless LAN 802.11 b/g/n1 x WWAN module |
电源管理 | Selectable boot-up & shut-down voltage for low power protectionHW design ready for 8-level delay time on/off at user's self configurationPower on/ off ignition, software detectableSupport S4 suspend mode; wake on RTC/ SMS |
尺寸 | 185.4 mm (W) x 141.4 mm (D) x 50.42 mm (H) (7.3" x 5.57" x 1.99")1 Kg (2.20 Lb) |
机构 | Plastic case with aluminum die casting heatsinkCompliant with IP54 |
环境 | Operating temperatures ambient with air: -20°C to 50°C
Storage temperatures: -30°C to 80°CRelative humidity: 10% to 90% (non-condensing)Vibration (random): 2g @5~500HzVibration
Operating: MIL-STD-810F, Method 514.5, Category 20, Ground Vehicle – Highway Truck
Storage: MIL-STD-810F, Method 514.5, Category 24, Integrity Test |
振动 | Operating: MIL-STD-810F, Method 516.5, Procedure I, Trucks and semi-trailers= 20gCrash Hazard: MIL-STD-810F, Method 516.5, Procedure V, Ground equipment= 75g |
通过认证 | CE approvalFCC Class Be13 Mark |
